Handheld Laser Welding Machine For Sheet Metal Processing

Zero-maintenance, air-cooled handheld laser welding systems engineered for sheet metal processing, kitchen and bathroom hardware, chassis and cabinets, doors/windows/guardrails, and advertising signage. Browse model variations, technical specifications, and related welding systems below.

Handheld Air-Cooled Laser Welding Machine Series

Product Line: Portable Air-Cooled Welding System

| Model | Power Rating | Category |

| LWM-1200F | 1200W | Handheld Air-Cooled Laser Welding Machine |

| LWM-1500F | 1500W | Handheld Air-Cooled Laser Welding Machine |

| LWM-2000F | 2000W | Handheld Air-Cooled Laser Welding Machine |

Equipment Parameters

• Cooling Method: Air-cooled
• Machine Weight: 75kg – 85kg
• Welding Speed: 0-20mm/s
• Optical Fiber Length: Standard 10 meters

Key Functions

• Air-Cooling Heat Dissipation System — high-temperature chip technology, supports 24-hour continuous operation
• Anti-High-Reflection Process — optimized for aluminum alloys and galvanized sheets
• Multiple Safety Protection — rust-proof light emission protection, over-temperature/over-voltage circuit monitoring

Industry Adaptation: Sheet metal processing, kitchen and bathroom hardware, chassis and cabinets, doors/windows/guardrails, advertising signage

Target Application: Solves the limitations of water-cooled welding machines — large volume, leakage/scaling risk, anti-freeze requirements in winter, and inconvenience in outdoor/high-altitude operations.

Related Handheld & Multi-Function Welding System

Handheld 5-in-1 Laser Welding Machine (LSW-1500 / LSW-2000 / LSW-3000)

Product Line: Multi-Functional Integrated Welding System

Equipment Parameters

• Spot Adjustment Range: Line 0-5mm
• Automatic Wire Feeding: Supported
• Welding Gap Requirement: <0.5mm
• External Dimensions: 1050×750×1170mm

Functions: Welding, cutting, cleaning, weld bead cleaning, and spot welding integrated in one unit; compatible with mainstream robots for multi-axis automated production line upgrades.

Industry Adaptation: Medical devices, microelectronic components, new energy tab welding, automotive manufacturing

Related Product Categories

Automated Multi-Axis Welding System

Multi-Axis Combined Laser Welding Machine (1500W / 2000W / 3000W)

• Input Power Supply: 220V/380V
• Welding Capacity (SS/CS): 0.2-5.0mm
• Aiming and Positioning: Infrared + CCD display screen
• Industry Adaptation: New energy lithium batteries, 3C electronics, precision hardware, sensor manufacturing

Platform Type Markless Laser Spot Welding System

Platform Type Laser Spot Welding Machine (LSW1500 / LSW2000 / LSW3000)

• Table Size: 1000x600 / 1200x800mm (customization supported)
• Welding Gun Type: Double-wobble welding head
• Welding Capacity (Aluminum): 0.2-4.0mm
• Positioning Method: Infrared
• Industry Adaptation: Automotive parts, power battery modules, lighting, compressors, smart terminals

High-Speed Scanning Welding System

Galvanometer Laser Welding Machine (1500W / 2000W / 3000W)

• Positioning Method: Infrared
• Welding Gap Requirement: 0.2mm
• Weight: 400KG – 440KG
• Standard Dimensions: 160×120×180CM
• Industry Adaptation: Power battery packs, aerospace thin-walled components, medical seals, sensors

Contact

For detailed technical datasheets, custom power configurations (1200W/1500W/2000W), or bulk pricing on handheld air-cooled laser welding machines for sheet metal processing, contact our engineering team through the official inquiry channel for a rapid response.
